ThermTec Cyclone 315 is most compact and lightweight thermal imaging monocular on the market, weighing only 255g. Features a NETD <20mK detector that delivers excellent image quality. AI self-learning algorithms that provide increasingly stable target image quality. With advanced features such as multi-target ranging, 20-hour battery life, and 3-second fast start-up, it is a great choice for close-range observations at an affordable price.
- Resolution: 384x288
- Pixel pitch: 12µm
- NETD: 20mK@300k
- Spectral range: 8-14µm
- Frame rate: 50HZ
- Detection range: 750m
- Objective lens: 15mm/F1.0
- Field of view: 17.5° x 13.1°
- / m @100m: 30.7m×23.0m
- Magnification: 1.4x
- Digital zoom: 1x, 2x, 4x
- Eye relief: 20mm
- Exit pupil: 6mm
- Dioptre: ±5D
- Type: AMOLED
- Display resolution: 1024x768
- Display size: 0.39 inch
- Colour palette: 6
- Image mode: Forest/Target/Outline
- Photo/video playback: Yes
- Language: Multiple-languages
|
- Inbuilt memory: 32GB
- Audio: Yes
- Calibration: Auto/Manual
- PIP: Yes
- AI Distance Measurement: Yes
- Heat track: Yes
- OSD recording: Yes
- Internal battery: Replaceable and Rechargeable Li-ion Battery (18650x1)
- Battery life: 10h
- Type-C: Supports battery charging, data transfer
- Hotspot: Yes, App remote control
- Working temperature: -20℃~+50℃
- Protection level: IP67
- Weight: 255g (without battery)
- Dimension: 135mm x 76mm x 54mm
- External cable: USB cable
|
